30kva kirloskar generator in Nepal

Engine:

  • O2E Series: Low emission, high efficiency engines
  • Compact, Robust and Rugged Design
  • 500 hours lube-oil change period

Controller:
  • Microprocessor based fully configured
  • Graphical bigger LCD display
  • Best in class monitoring and diagnostic
  • Integrable with AMF

Kirloskar generator in Nepal

Monitoring Features
  • Lube oil Pressure, Engine Temperature, RPM, lube oil Temperature*
  • Run Hours, No. of starts, Fuel Level, Auto / Manual Stop, BaMery charge condition, AC Phase Voltage, Current, kVA, kW, kWh, kVAr, Power Factor
Optional Features
  • Mod bus communication*
  • * Features are available from 15 kVA onwards
Diagnostic Features
  • Battery charging failure, Over speed, Under speed, Over Current, Under Voltage, Over Voltage, Over kW, Phase Sequence monitoring, Phase missing, Common Alarm, Hooter output
  • Low lube oil Pressure, High Engine Temperature, Low/High battery voltage, Low Fuel Level alarm, Over Crank protection, Routine Maintenance indicator, Generator Test Facility, fail to start/stop

Top Generators/ Engines service company in Nepal.

Himal trade link pvt.ltd
satdobato, ring-road, lalitpur, Nepal
Phone : 015553931
Mobile: 9805226000
Email : himaltradelink@gmail.com
Website : www.himaltradelink.com.np

15 Kva Kirloskar iGreen Generators in Nepal.

Overview & Full Specifications of Kirloskar 15 Kva generator

Fuel Type:Diesel
Cylinders:2
Phase:Three Phase
Warranty:0
Power Rating Range:15
Fuel Tank Capacity Range:50 Litres
Weight Range:900
Speed:1500 rpm
Battery Capacity:80 Ah
Style:Standby Generators
LxWxH(Weight):2000x1025x1425
Rating (kVA):15
Rated kW:12
BHP:21.75

Kirloskar Nepal || Kirloskar 30 Kva Generator

Kirloskar Nepal

We provide kirloskar (KOEL) generators or engines and their servicing/maintenance in Nepal. Beside that our company deals with cheap value, low cost, reliable service with briefly amount of your time .

Kirloskar 5 Kva - 12.5 Kva Generator suppliers in Nepal.

Product Specifications

Prime Rating at rated rpm ( as per ISO8528)1

kVA

5

7.5

10

12.5

kW

4

6

8

10

Genset Model



KG1-5AS3

KG1-7.5AS4

KG1-10AS5

KG1-12.5AS2

Frequency

Hz

50

Power factor

lagging

0.8

Voltage

V

230 (1Ø) & 415 (3Ø)

Governing class (As per ISO 8528 Part-V)



G2

Noise level

dBA

< 75

Fuel Consumption*

At 100% Load

Ltrs/hr

1.60

2.21

3.00

3.45

At 75% Load

1.30

1.62

2.40

2.65

At 50% Load

1.0

1.21

1.80

1.94

Fuel tank capacity

Ltrs

50

50

50

50

Weight of genset with canopy (approx..)^

Dry

Kg

670

680

750

840

Wet

Kg

720

730

800

890

Overall dimensions of genset^

Length

mm

1310

1310

1760

1760

Width

mm

810

810

820

820

Height

mm

1330

1330

1330

1330

Electrical Battery starting voltage

Volts-DC

12

ENGINE

Engine Model



EA10 G1

EA10 G1

EA16 G1

EA16 G1

Rated output (Prime Continuous rating as per ISO 8528-1)

kW

7.3

7.3

11.8

11.8

HP

10

10

16

16

Cooling System

Air

No. of cylinder

Number

1

1

2

2

Cubic capacity

Ltrs

0.95

0.95

1.56

1.56

Bore x Stroke

mm

102 x 116

102 x 116

95 x 110

95 x 110

Rated Speed

RPM

1500

1500

1500

1500

Aspiration

NA/TC/TA

NA

NA

NA

NA

Lube Oil change period

Hrs

500 hrs

Lube Oil Sump Capacity

Ltrs

3.5

3.5

6.5

6.5

Coolant Capacity

Ltrs

NA

NA

NA

NA

ALTERNATOR

Insulation Class



Class H

Alternator Efficiency (at 100% load) 0.8 pf**

%

78.1

82.5

82.6

84.9

Max Voltage Dip at Full Load 0.8 pf Lag

Sec

< 20%

Max Time to build up rated voltage at Rated RPM

< 5 sec provided engine reach the rated speed
